CTM PWH 4.0 1611

CTM  PWH 4.0 1611

High pressure cleaners >  Hot water high pressure cleaners
FUEL / AUTOMOTIVE / SPA / HORECA / SANITARY / GDO / PUBLIC
Code: 8.630.0109
PWH 4.0 1611
Made in Italy

Features

4 poles electrical motor (1450 RPM) with thermal protection. Three ceramic coated pistons, brass linear pump head with built-in by-pass valve. Low voltage and delayed Total Stop. Suction and delivery valves s/s. Vertical burner with high thermal efficiency steel coil. Temperature regulation gauge withsensitive stainless steel coil. Low fuel light lamp bulb and cut off. Safety valve. Built-in detergent tank for indirect suction. Auxiliary motor for burner. Hose-reel (optional).

Technical characteristics

Operating pressure (max) 120 (150) bar/psi
Delivery rate 660 l./h - GPM
Absorbed power 3000 W
Voltage 230V-50Hz/1Ph
Motopump type MP4
RPM 1450
Detergent tank capacity 16 l.
Max temperature inlet/outlet 40/140 °C
Fuel consumption/heat output 4,72 l/h-58 kW
Machine dimensions 94x65x90 cm
Machine weight 112 kg

Standard accessories

M22-gun 3/8 with Swivel

M22-gun 3/8 with Swivel

High/low pressure nozzle M22

High/low pressure nozzle M22

045 nozzle

045 nozzle

R1 hose 10 m high pressure

R1 hose 10 m high pressure
